Timken 11165X - 11315 bearing

All our Timken 11165X - 11315 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 11165X - 11315

Series

11000

Cone Part Number

11165X

Cup Part Number

11315

Design Units

Imperial

Bearing Weight

0.8000 lb
0.4000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.1496 in
80.000 mm

d - Cone Bore

1.6535 in
41.999 mm

B - Cone Width

0.6844 in
17.384 mm

C - Cup Width

0.5625 in
14.288 mm

T - Bearing Width

0.7090 in
18.009 mm

Z - Number of Rollers Per Row

19

R - Cone Backface "To Clear" Radius¹

0.070 in
1.780 mm

r - Cup Backface "To Clear" Radius²

0.060 in
1.52 mm

da - Cone Frontface Backing Diameter

1.85 in
46.99 mm

db - Cone Backface Backing Diameter

1.97 in
50.04 mm

Da - Cup Frontface Backing Diameter

2.91 in
73.90 mm

Db - Cup Backface Backing Diameter

2.72 in
69.09 mm

Ab - Cage-Cone Frontface Clearance

0 in
0.00 mm

Aa - Cage-Cone Backface Clearance

0.00 in
0.00 mm

a - Effective Center Location³

-0.03 in
-0.80 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

2800 lbf
12500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

10800 lbf
48100 N

C0 - Static Radial Rating

12400 lbf
55100 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

2340 lbf
10400 N

K - Factor¹

1.2

e - ISO Factor²

0.49

Y - ISO Factor³

1.23

G1 - Heat Generation Factor (Roller-Raceway)

19.2

G2 - Heat Generation Factor (Rib-Roller End)

12.8

Cg - Geometry Factor

0.0735

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 11165X - 11315 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 11165X - 11315 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Timken price SPEC Tapered Roller 11165X - 11315 Bearings_TS -Tancbearing

11165X - 11315 bearing
11165X - 11315 bearing
11165X - 11315 bearing
11165X - 11315 bearing
11165X - 11315 bearing
11165X - 11315 bearing
11165X - 11315 bearing
11165X - 11315 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Cr:

44500N

d:

42.000mm

Brand:

TIMKENBearing

C0r:

55100N

m:

0.38kg

Model:

11165X/11315

B:

17.384mm

Category:

TaperedRollerBearings

D:

80.000mm
