Timken 4395 - 4335 bearing

All our Timken 4395 - 4335 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 4395 - 4335

Series

4300

Cone Part Number

4395

Cup Part Number

4335

Design Units

Imperial

Bearing Weight

2.7000 lb
1.2000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.5625 in
90.488 mm

d - Cone Bore

1.6563 in
42.070 mm

B - Cone Width

1.5900 in
40.386 mm

C - Cup Width

1.3125 in
33.338 mm

T - Bearing Width

1.5625 in
39.688 mm

Z - Number of Rollers Per Row

15

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.05 in
52.07 mm

db - Cone Backface Backing Diameter

2.36 in
59.94 mm

Da - Cup Frontface Backing Diameter

3.39 in
85.10 mm

Db - Cup Backface Backing Diameter

3.03 in
76.96 mm

Ab - Cage-Cone Frontface Clearance

0.02 in
0.51 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.59 in
-15.00 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

11600 lbf
51500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

44700 lbf
199000 N

C0 - Static Radial Rating

45900 lbf
204000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

5640 lbf
25100 N

K - Factor¹

2.05

e - ISO Factor²

0.28

Y - ISO Factor³

2.11

G1 - Heat Generation Factor (Roller-Raceway)

52.9

G2 - Heat Generation Factor (Rib-Roller End)

14.3

Cg - Geometry Factor

0.0872

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 4395 - 4335 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 4395 - 4335 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

SPEC Tapered Roller 4395 - 4335 Bearings_TS specifications Timken -Tancbearing

4395 - 4335 bearing
4395 - 4335 bearing
4395 - 4335 bearing
4395 - 4335 bearing
4395 - 4335 bearing
4395 - 4335 bearing
4395 - 4335 bearing
4395 - 4335 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Category:

TaperedRollerBearings

m:

1.24kg

C0r:

175N

GreaseRPM:

43001/min

OilRPM:

58001/min

B:

40.386mm

Brand:

NTNBearing

D:

90.488mm

d:

42.07mm

NewModel:

4T-4395/4335

Cr:

136N

Model:

4T-4395/4335

Model:

4395/4335

Cr:

132N

D:

90.488mm

GreaseRPM:

45001/min

B:

40.386mm

Brand:

KOYOBearing

d:

42.07mm

OilRPM:

60001/min

Category:

TaperedRollerBearings

C0r:

169N

m:

1.21kg
