Timken 461 - 453 bearing

All our Timken 461 - 453 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken 461 - 453

Series 455
Cone Part Number 461
Cup Part Number 453
Design Units Imperial
Bearing Weight 3.1000 lb
1.4000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 4.2500 in
107.950 mm
d - Cone Bore 1.6870 in
42.850 mm
B - Cone Width 1.1542 in
29.317 mm
C - Cup Width 1.0630 in
27.000 mm
T - Bearing Width 1.0943 in
27.795 mm
Z - Number of Rollers Per Row 18
R - Cone Backface "To Clear" Radius1 0.030 in
0.760 mm
r - Cup Backface "To Clear" Radius2 0.030 in
0.76 mm
da - Cone Frontface Backing Diameter 2.09 in
53.09 mm
db - Cone Backface Backing Diameter 2.13 in
54.10 mm
Da - Cup Frontface Backing Diameter 3.96 in
100.10 mm
Db - Cup Backface Backing Diameter 3.82 in
97.03 mm
Ab - Cage-Cone Frontface Clearance 0.05 in
1.27 mm
Aa - Cage-Cone Backface Clearance 0.09 in
2.29 mm
a - Effective Center Location3 -0.28 in
-7.10 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 7900 lbf
35200 N
C1 - Dynamic Radial Rating (1 million revolutions)2 30500 lbf
136000 N
C0 - Static Radial Rating 37200 lbf
166000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 4540 lbf
20200 N
K - Factor1 1.74
e - ISO Factor2 0.34
Y - ISO Factor3 1.79
G1 - Heat Generation Factor (Roller-Raceway) 58.6
G2 - Heat Generation Factor (Rib-Roller End) 17.1
Cg - Geometry Factor 0.0946


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken 461 - 453 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken 461 - 453 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



Tapered Roller 461 - 453 Bearings_TS specifications Timken dimensions -Tancbearing
