Timken HM803145 - HM803110 bearing

All our Timken HM803145 - HM803110 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken HM803145 - HM803110

Series

HM803100

Cone Part Number

HM803145

Cup Part Number

HM803110

Design Units

Imperial

Bearing Weight

2.0000 lb
0.9000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.5000 in
88.900 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.1563 in
29.370 mm

C - Cup Width

0.9063 in
23.020 mm

T - Bearing Width

1.1875 in
30.163 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.030 in
0.760 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.09 in
53.09 mm

db - Cone Backface Backing Diameter

2.13 in
54.10 mm

Da - Cup Frontface Backing Diameter

3.39 in
85.10 mm

Db - Cup Backface Backing Diameter

2.91 in
73.91 mm

Ab - Cage-Cone Frontface Clearance

0.08 in
2.03 mm

Aa - Cage-Cone Backface Clearance

0.06 in
1.52 mm

a - Effective Center Location³

-0.17 in
-4.30 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

6630 lbf
29500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

25600 lbf
114000 N

C0 - Static Radial Rating

32400 lbf
144000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

6200 lbf
27600 N

K - Factor¹

1.07

e - ISO Factor²

0.55

Y - ISO Factor³

1.1

G1 - Heat Generation Factor (Roller-Raceway)

39.2

G2 - Heat Generation Factor (Rib-Roller End)

13.7

Cg - Geometry Factor

0.0974

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken HM803145 - HM803110 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken HM803145 - HM803110 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

sale Timken dimensions Tapered Roller HM803145 - HM803110 Bearings_TS -Tancbearing

HM803145 - HM803110 bearing
HM803145 - HM803110 bearing
HM803145 - HM803110 bearing
HM803145 - HM803110 bearing
HM803145 - HM803110 bearing
HM803145 - HM803110 bearing
HM803145 - HM803110 bearing
HM803145 - HM803110 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Cr:

99.6N

m:

0.895kg

Category:

TaperedRollerBearings

OilRPM:

61001/min

C0r:

125N

d:

41.275mm

B:

29.37mm

Brand:

KOYOBearing

D:

88.9mm

GreaseRPM:

46001/min

Model:

HM803145/HM803110

Category:

TaperedRollerBearings

d:

41.275mm

D:

88.900mm

Brand:

TIMKENBearing

C0r:

144000N

m:

0.9kg

B:

29.370mm

Cr:

105000N

Model:

HM803145/HM803110

d:

41.275mm

m:

0.98kg

Brand:

TIMKENBearing

C0r:

144000N

B:

29.370mm

Category:

TaperedRollerBearings

Model:

HM803145/HM803112

Cr:

105000N

D:

92.075mm

m:

0.901kg

Brand:

NTNBearing

NewModel:

4T-HM803145/HM803110

Model:

4T-HM803145/HM803110

Category:

TaperedRollerBearings

Cr:

93.5N

B:

29.37mm

C0r:

125N

d:

41.275mm

D:

88.9mm

GreaseRPM:

43001/min

OilRPM:

58001/min
