Timken HM804840 - HM804810 bearing

All our Timken HM804840 - HM804810 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken HM804840 - HM804810

Series

HM804800

Cone Part Number

HM804840

Cup Part Number

HM804810

Design Units

Imperial

Bearing Weight

2.4000 lb
1.1000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.7500 in
95.250 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.1563 in
29.370 mm

C - Cup Width

0.9063 in
23.020 mm

T - Bearing Width

1.1875 in
30.163 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.13 in
54.10 mm

db - Cone Backface Backing Diameter

2.40 in
60.96 mm

Da - Cup Frontface Backing Diameter

3.62 in
91.90 mm

Db - Cup Backface Backing Diameter

3.19 in
81.03 mm

Ab - Cage-Cone Frontface Clearance

0.11 in
2.79 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.15 in
-3.80 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

8590 lbf
38200 N

C1 - Dynamic Radial Rating (1 million revolutions)²

33100 lbf
147000 N

C0 - Static Radial Rating

35400 lbf
157000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

8030 lbf
35700 N

K - Factor¹

1.07

e - ISO Factor²

0.55

Y - ISO Factor³

1.1

G1 - Heat Generation Factor (Roller-Raceway)

44.8

G2 - Heat Generation Factor (Rib-Roller End)

13.8

Cg - Geometry Factor

0.102

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken HM804840 - HM804810 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken HM804840 - HM804810 Bearings, welcome to your calling.
