Timken HM807035 - HM807010 bearing

All our Timken HM807035 - HM807010 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken HM807035 - HM807010

Series

HM807000

Cone Part Number

HM807035

Cup Part Number

HM807010

Design Units

Imperial

Bearing Weight

3.7000 lb
1.7000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

4.1250 in
104.775 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.4375 in
36.513 mm

C - Cup Width

1.1250 in
28.575 mm

T - Bearing Width

1.4375 in
36.513 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.060 in
1.520 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

2.24 in
56.90 mm

db - Cone Backface Backing Diameter

2.36 in
59.94 mm

Da - Cup Frontface Backing Diameter

3.96 in
100.10 mm

Db - Cup Backface Backing Diameter

3.50 in
88.90 mm

Ab - Cage-Cone Frontface Clearance

0.08 in
2.03 mm

Aa - Cage-Cone Backface Clearance

0.14 in
3.56 mm

a - Effective Center Location³

-0.29 in
-7.40 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

10000 lbf
44500 N

C1 - Dynamic Radial Rating (1 million revolutions)²

38600 lbf
172000 N

C0 - Static Radial Rating

50200 lbf
223000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

8350 lbf
37100 N

K - Factor¹

1.2

e - ISO Factor²

0.49

Y - ISO Factor³

1.23

G1 - Heat Generation Factor (Roller-Raceway)

63.9

G2 - Heat Generation Factor (Rib-Roller End)

17.1

Cg - Geometry Factor

0.076

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken HM807035 - HM807010 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken HM807035 - HM807010 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

specifications Tapered Roller HM807035 - HM807010 Bearings_TS dimensions Timken -Tancbearing

HM807035 - HM807010 bearing
HM807035 - HM807010 bearing
HM807035 - HM807010 bearing
HM807035 - HM807010 bearing
HM807035 - HM807010 bearing
HM807035 - HM807010 bearing
HM807035 - HM807010 bearing
HM807035 - HM807010 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

OilRPM:

51001/min

Category:

TaperedRollerBearings

GreaseRPM:

38001/min

D:

104.775mm

d:

41.275mm

Model:

HM807035/HM807010

Cr:

141N

Brand:

KOYOBearing

B:

36.512mm

m:

1.687kg

C0r:

195N

Model:

HM807035/HM807010

m:

1.66kg

d:

41.275mm

Brand:

TIMKENBearing

Cr:

159000N

B:

36.512mm

D:

104.775mm

C0r:

223000N

Category:

TaperedRollerBearings
