Timken HM903244 - HM903210 bearing

All our Timken HM903244 - HM903210 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken HM903244 - HM903210

Series HM903200
Cone Part Number HM903244
Cup Part Number HM903210
Design Units Imperial
Bearing Weight 2.3000 lb
1.0000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 3.7500 in
95.250 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 1.1142 in
28.301 mm
C - Cup Width 0.8750 in
22.225 mm
T - Bearing Width 1.2188 in
30.958 mm
Z - Number of Rollers Per Row 16
R - Cone Backface "To Clear" Radius1 0.060 in
1.520 mm
r - Cup Backface "To Clear" Radius2 0.030 in
0.76 mm
da - Cone Frontface Backing Diameter 2.13 in
54.10 mm
db - Cone Backface Backing Diameter 2.32 in
58.93 mm
Da - Cup Frontface Backing Diameter 3.62 in
91.90 mm
Db - Cup Backface Backing Diameter 3.19 in
81.03 mm
Ab - Cage-Cone Frontface Clearance 0.09 in
2.29 mm
Aa - Cage-Cone Backface Clearance 0.16 in
4.06 mm
a - Effective Center Location3 0.02 in
0.50 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 7950 lbf
35400 N
C1 - Dynamic Radial Rating (1 million revolutions)2 30700 lbf
136000 N
C0 - Static Radial Rating 29700 lbf
132000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 10100 lbf
44800 N
K - Factor1 0.79
e - ISO Factor2 0.74
Y - ISO Factor3 0.81
G1 - Heat Generation Factor (Roller-Raceway) 33.7
G2 - Heat Generation Factor (Rib-Roller End) 9.91
Cg - Geometry Factor 0.101


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken HM903244 - HM903210 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken HM903244 - HM903210 Bearings, welcome to your calling.
