Timken HM903244 - HM903216 bearing

All our Timken HM903244 - HM903216 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken HM903244 - HM903216

Series HM903200
Cone Part Number HM903244
Cup Part Number HM903216
Design Units Imperial
Bearing Weight 2.5000 lb
1.1000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 3.8750 in
98.425 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 1.1142 in
28.301 mm
C - Cup Width 0.8750 in
22.225 mm
T - Bearing Width 1.2188 in
30.958 mm
Z - Number of Rollers Per Row 16
R - Cone Backface "To Clear" Radius1 0.060 in
1.520 mm
r - Cup Backface "To Clear" Radius2 0.030 in
0.76 mm
da - Cone Frontface Backing Diameter 2.13 in
54.10 mm
db - Cone Backface Backing Diameter 2.32 in
58.93 mm
Da - Cup Frontface Backing Diameter 3.66 in
92.96 mm
Db - Cup Backface Backing Diameter 3.23 in
82.04 mm
Ab - Cage-Cone Frontface Clearance 0.09 in
2.29 mm
Aa - Cage-Cone Backface Clearance 0.16 in
4.06 mm
a - Effective Center Location3 0.02 in
0.50 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 7950 lbf
35400 N
C1 - Dynamic Radial Rating (1 million revolutions)2 30700 lbf
136000 N
C0 - Static Radial Rating 29700 lbf
132000 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 10100 lbf
44800 N
K - Factor1 0.79
e - ISO Factor2 0.74
Y - ISO Factor3 0.81
G1 - Heat Generation Factor (Roller-Raceway) 33.7
G2 - Heat Generation Factor (Rib-Roller End) 9.91
Cg - Geometry Factor 0.101


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken HM903244 - HM903216 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken HM903244 - HM903216 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



Timken price Tapered Roller HM903244 - HM903216 Bearings_TS sale -Tancbearing

  • bearing HM903244 - HM903216 bearing
  • bearing HM903244 - HM903216 bearing
  • bearing HM903244 - HM903216 bearing
  • bearing HM903244 - HM903216 bearing
  • bearing HM903244 - HM903216 bearing
  • bearing HM903244 - HM903216 bearing
  • bearing HM903244 - HM903216 bearing
  • bearing HM903244 - HM903216 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 Brand:
TIMKENBearing
Cr:
107000N
D:
98.425mm
d:
41.275mm
C0r:
132000N
Category:
TaperedRollerBearings
m:
1.13kg
B:
28.300mm
Model:
HM903244/HM903216
Brand:
TIMKENBearing
Category:
TaperedRollerBearings
Cr:
107000N
D:
95.250mm
Model:
HM903244/HM903210
B:
28.300mm
C0r:
132000N
m:
1.04kg
d:
41.275mm
