Timken HM903245 - HM903210 bearing

All our Timken HM903245 - HM903210 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken HM903245 - HM903210

Series

HM903200

Cone Part Number

HM903245

Cup Part Number

HM903210

Design Units

Imperial

Bearing Weight

2.3000 lb
1.0000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.7500 in
95.250 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.1250 in
28.575 mm

C - Cup Width

0.8750 in
22.225 mm

T - Bearing Width

1.2188 in
30.958 mm

Z - Number of Rollers Per Row

16

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.030 in
0.76 mm

da - Cone Frontface Backing Diameter

2.13 in
54.10 mm

db - Cone Backface Backing Diameter

2.48 in
62.99 mm

Da - Cup Frontface Backing Diameter

3.62 in
91.90 mm

Db - Cup Backface Backing Diameter

3.19 in
81.03 mm

Ab - Cage-Cone Frontface Clearance

0.08 in
2.03 mm

Aa - Cage-Cone Backface Clearance

0.16 in
4.06 mm

a - Effective Center Location³

0.02 in
0.50 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

7950 lbf
35400 N

C1 - Dynamic Radial Rating (1 million revolutions)²

30700 lbf
136000 N

C0 - Static Radial Rating

29700 lbf
132000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

10100 lbf
44800 N

K - Factor¹

0.79

e - ISO Factor²

0.74

Y - ISO Factor³

0.81

G1 - Heat Generation Factor (Roller-Raceway)

33.7

G2 - Heat Generation Factor (Rib-Roller End)

9.91

Cg - Geometry Factor

0.101

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken HM903245 - HM903210 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken HM903245 - HM903210 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

SPEC Timken sale Tapered Roller HM903245 - HM903210 Bearings_TS -Tancbearing

HM903245 - HM903210 bearing
HM903245 - HM903210 bearing
HM903245 - HM903210 bearing
HM903245 - HM903210 bearing
HM903245 - HM903210 bearing
HM903245 - HM903210 bearing
HM903245 - HM903210 bearing
HM903245 - HM903210 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

C0r:

132000N

m:

1.04kg

D:

95.250mm

d:

41.275mm

B:

28.575mm

Cr:

107000N

Category:

TaperedRollerBearings

Brand:

TIMKENBearing

Model:

HM903245/HM903210

d:

41.275mm

Model:

4T-HM903245/HM903210

Category:

TaperedRollerBearings

m:

1.05kg

NewModel:

4T-HM903245/HM903210

D:

95.25mm

OilRPM:

49001/min

Brand:

NTNBearing

Cr:

96N

B:

28.575mm

GreaseRPM:

37001/min

C0r:

116N
