Timken LM300848 - LM300811 bearing

All our Timken LM300848 - LM300811 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken LM300848 - LM300811

Series

LM300800

Cone Part Number

LM300848

Cup Part Number

LM300811

Design Units

Imperial

Bearing Weight

0.5000 lb
0.2000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

2.6762 in
67.975 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

0.7087 in
18.001 mm

C - Cup Width

0.5315 in
13.500 mm

T - Bearing Width

0.6890 in
17.501 mm

Z - Number of Rollers Per Row

22

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.060 in
1.52 mm

da - Cone Frontface Backing Diameter

1.79 in
45.47 mm

db - Cone Backface Backing Diameter

2.05 in
52.07 mm

Da - Cup Frontface Backing Diameter

2.60 in
66.00 mm

Db - Cup Backface Backing Diameter

2.40 in
60.96 mm

Ab - Cage-Cone Frontface Clearance

0.05 in
1.27 mm

Aa - Cage-Cone Backface Clearance

0.03 in
0.76 mm

a - Effective Center Location³

-0.14 in
-3.60 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

2900 lbf
12900 N

C1 - Dynamic Radial Rating (1 million revolutions)²

11200 lbf
49800 N

C0 - Static Radial Rating

14300 lbf
63500 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

1730 lbf
7710 N

K - Factor¹

1.68

e - ISO Factor²

0.35

Y - ISO Factor³

1.72

G1 - Heat Generation Factor (Roller-Raceway)

22.5

G2 - Heat Generation Factor (Rib-Roller End)

16.6

Cg - Geometry Factor

0.0698

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken LM300848 - LM300811 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken LM300848 - LM300811 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Timken price Tapered Roller LM300848 - LM300811 Bearings_TS sale -Tancbearing

LM300848 - LM300811 bearing
LM300848 - LM300811 bearing
LM300848 - LM300811 bearing
LM300848 - LM300811 bearing
LM300848 - LM300811 bearing
LM300848 - LM300811 bearing
LM300848 - LM300811 bearing
LM300848 - LM300811 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Cr:

46100N

d:

41.275mm

m:

0.24kg

B:

18.000mm

D:

67.975mm

Brand:

TIMKENBearing

C0r:

63500N

Category:

TaperedRollerBearings

Model:

LM300848/LM300811
