Timken LM501349A - LM501310 bearing

All our Timken LM501349A - LM501310 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken LM501349A - LM501310

Series

LM501300

Cone Part Number

LM501349A

Cup Part Number

LM501310

Design Units

Imperial

Bearing Weight

0.7000 lb
0.3000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

2.8910 in
73.431 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

0.7800 in
19.812 mm

C - Cup Width

0.5800 in
14.732 mm

T - Bearing Width

0.7700 in
19.558 mm

Z - Number of Rollers Per Row

19

R - Cone Backface "To Clear" Radius¹

0.030 in
0.760 mm

r - Cup Backface "To Clear" Radius²

0.030 in
0.76 mm

da - Cone Frontface Backing Diameter

1.83 in
46.48 mm

db - Cone Backface Backing Diameter

1.85 in
46.99 mm

Da - Cup Frontface Backing Diameter

2.80 in
71.10 mm

Db - Cup Backface Backing Diameter

2.64 in
67.06 mm

Ab - Cage-Cone Frontface Clearance

0.04 in
1.02 mm

Aa - Cage-Cone Backface Clearance

0.04 in
1.02 mm

a - Effective Center Location³

-0.13 in
-3.30 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

4360 lbf
19400 N

C1 - Dynamic Radial Rating (1 million revolutions)²

16800 lbf
74800 N

C0 - Static Radial Rating

16700 lbf
74200 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

2980 lbf
13300 N

K - Factor¹

1.46

e - ISO Factor²

0.4

Y - ISO Factor³

1.5

G1 - Heat Generation Factor (Roller-Raceway)

23.3

G2 - Heat Generation Factor (Rib-Roller End)

13.3

Cg - Geometry Factor

0.0739

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken LM501349A - LM501310 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken LM501349A - LM501310 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

specifications Timken price Tapered Roller LM501349A - LM501310 Bearings_TS -Tancbearing

LM501349A - LM501310 bearing
LM501349A - LM501310 bearing
LM501349A - LM501310 bearing
LM501349A - LM501310 bearing
LM501349A - LM501310 bearing
LM501349A - LM501310 bearing
LM501349A - LM501310 bearing
LM501349A - LM501310 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

d:

41.275mm

Brand:

TIMKENBearing

D:

73.431mm

m:

0.37kg

B:

19.812mm

Category:

TaperedRollerBearings

C0r:

74200N

Cr:

58400N

Model:

LM501349/LM501311

d:

41.275mm

Model:

KLM501349.LM501310

C0r:

68000N

Category:

TaperedRollerBearings

m:

0.365kg

B:

19.812mm

NewModel:

KLM501349-LM501310

GreaseRPM:

—1/min

OilRPM:

94001/min

Brand:

FAGBearing

D:

73.431mm

Cr:

55000N

OldModel:

KLM501349.LM501310

Model:

LM501349/LM501314

Category:

TaperedRollerBearings

d:

41.275mm

m:

0.36kg

Cr:

58400N

Brand:

TIMKENBearing

B:

19.812mm

D:

73.431mm

C0r:

74200N

Cr:

58400N

B:

19.812mm

m:

0.33kg

Model:

LM501349A/LM501310

Brand:

TIMKENBearing

d:

41.275mm

Category:

TaperedRollerBearings

D:

73.431mm

C0r:

74200N

C0r:

73000N

d:

41.275mm

OilRPM:

61001/min

B:

19.812mm

Model:

H-LM501349/H-LM501314

D:

73.431mm

GreaseRPM:

44001/min

Category:

TaperedRollerBearings

Cr:

57800N

Brand:

NACHIBearing

m:

0.355kg

Category:

TaperedRollerBearings

D:

73.431mm

Brand:

KOYOBearing

OilRPM:

70001/min

GreaseRPM:

52001/min

d:

41.275mm

Model:

LM501349/LM501314

Cr:

57.8N

m:

0.353kg

C0r:

73N

B:

19.812mm
