Timken LM501349 - LM501310 bearing

All our Timken LM501349 - LM501310 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken LM501349 - LM501310

Series LM501300
Cone Part Number LM501349
Cup Part Number LM501310
Design Units Imperial
Bearing Weight 0.7000 lb
0.3000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 2.8910 in
73.431 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 0.7800 in
19.812 mm
C - Cup Width 0.5800 in
14.732 mm
T - Bearing Width 0.7700 in
19.558 mm
Z - Number of Rollers Per Row 19
R - Cone Backface "To Clear" Radius1 0.140 in
3.560 mm
r - Cup Backface "To Clear" Radius2 0.030 in
0.76 mm
da - Cone Frontface Backing Diameter 1.89 in
48.01 mm
db - Cone Backface Backing Diameter 2.13 in
54.10 mm
Da - Cup Frontface Backing Diameter 2.80 in
71.10 mm
Db - Cup Backface Backing Diameter 2.64 in
67.06 mm
Ab - Cage-Cone Frontface Clearance 0.04 in
1.02 mm
Aa - Cage-Cone Backface Clearance 0.04 in
1.02 mm
a - Effective Center Location3 -0.13 in
-3.30 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 4360 lbf
19400 N
C1 - Dynamic Radial Rating (1 million revolutions)2 16800 lbf
74800 N
C0 - Static Radial Rating 16700 lbf
74200 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 2980 lbf
13300 N
K - Factor1 1.46
e - ISO Factor2 0.4
Y - ISO Factor3 1.5
G1 - Heat Generation Factor (Roller-Raceway) 23.3
G2 - Heat Generation Factor (Rib-Roller End) 13.3
Cg - Geometry Factor 0.0739


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken LM501349 - LM501310 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken LM501349 - LM501310 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



sale Timken Tapered Roller LM501349 - LM501310 Bearings_TS dimensions -Tancbearing

  • bearing LM501349 - LM501310 bearing
  • bearing LM501349 - LM501310 bearing
  • bearing LM501349 - LM501310 bearing
  • bearing LM501349 - LM501310 bearing
  • bearing LM501349 - LM501310 bearing
  • bearing LM501349 - LM501310 bearing
  • bearing LM501349 - LM501310 bearing
  • bearing LM501349 - LM501310 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 Model:
LM501349A/LM501310
C0r:
74200N
Brand:
TIMKENBearing
Category:
TaperedRollerBearings
Cr:
58400N
B:
19.812mm
D:
73.431mm
d:
41.275mm
m:
0.33kg
OilRPM:
70001/min
d:
41.275mm
Model:
LM501349/LM501314
D:
73.431mm
C0r:
73N
Cr:
57.8N
GreaseRPM:
52001/min
Brand:
KOYOBearing
m:
0.353kg
Category:
TaperedRollerBearings
B:
19.812mm
d:
41.275mm
m:
0.36kg
Brand:
TIMKENBearing
C0r:
74200N
Cr:
58400N
Category:
TaperedRollerBearings
D:
73.431mm
B:
19.812mm
Model:
LM501349/LM501314
OilRPM:
70001/min
Cr:
57.8N
B:
19.812mm
d:
41.275mm
Brand:
KOYOBearing
Category:
TaperedRollerBearings
m:
0.334kg
C0r:
73N
D:
73.431mm
GreaseRPM:
52001/min
Model:
LM501349/LM501310
d:
41.275mm
GreaseRPM:
44001/min
m:
0.335kg
OilRPM:
61001/min
Brand:
NACHIBearing
Category:
TaperedRollerBearings
Model:
H-LM501349/H-LM501310
B:
19.812mm
C0r:
73000N
D:
73.431mm
Cr:
57800N
D:
73.431mm
m:
0.355kg
Cr:
56N
GreaseRPM:
50001/min
B:
19.812mm
Model:
4T-LM501349/LM501314
Category:
TaperedRollerBearings
OilRPM:
66001/min
Brand:
NTNBearing
NewModel:
4T-LM501349/LM501314
d:
41.275mm
C0r:
69.5N
