Timken LM501349 - LM501310A bearing

All our Timken LM501349 - LM501310A bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken LM501349 - LM501310A

Series LM501300
Cone Part Number LM501349
Cup Part Number LM501310A
Design Units Imperial
Bearing Weight 0.7000 lb
0.3000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 2.8910 in
73.431 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 0.7800 in
19.812 mm
C - Cup Width 0.5800 in
14.732 mm
T - Bearing Width 0.7700 in
19.558 mm
Z - Number of Rollers Per Row 19
R - Cone Backface "To Clear" Radius1 0.140 in
3.560 mm
r - Cup Backface "To Clear" Radius2 0.060 in
1.52 mm
da - Cone Frontface Backing Diameter 1.89 in
48.01 mm
db - Cone Backface Backing Diameter 2.13 in
54.10 mm
Da - Cup Frontface Backing Diameter 2.80 in
71.10 mm
Db - Cup Backface Backing Diameter 2.60 in
66.04 mm
Ab - Cage-Cone Frontface Clearance 0.04 in
1.02 mm
Aa - Cage-Cone Backface Clearance 0.04 in
1.02 mm
a - Effective Center Location3 -0.13 in
-3.30 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 4360 lbf
19400 N
C1 - Dynamic Radial Rating (1 million revolutions)2 16800 lbf
74800 N
C0 - Static Radial Rating 16700 lbf
74200 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 2980 lbf
13300 N
K - Factor1 1.46
e - ISO Factor2 0.4
Y - ISO Factor3 1.5
G1 - Heat Generation Factor (Roller-Raceway) 23.3
G2 - Heat Generation Factor (Rib-Roller End) 13.3
Cg - Geometry Factor 0.0739


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken LM501349 - LM501310A Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken LM501349 - LM501310A Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



price Timken dimensions Tapered Roller LM501349 - LM501310A Bearings_TS -Tancbearing
