Timken LM501349 - LM501311 bearing

All our Timken LM501349 - LM501311 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken LM501349 - LM501311

Series LM501300
Cone Part Number LM501349
Cup Part Number LM501311
Design Units Imperial
Bearing Weight 0.8000 lb
0.4000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 2.8910 in
73.431 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 0.7800 in
19.812 mm
C - Cup Width 0.7160 in
18.186 mm
T - Bearing Width 0.9060 in
23.012 mm
Z - Number of Rollers Per Row 19
R - Cone Backface "To Clear" Radius1 0.140 in
3.560 mm
r - Cup Backface "To Clear" Radius2 0.090 in
2.29 mm
da - Cone Frontface Backing Diameter 1.89 in
48.01 mm
db - Cone Backface Backing Diameter 2.13 in
54.10 mm
Da - Cup Frontface Backing Diameter 2.80 in
71.10 mm
Db - Cup Backface Backing Diameter 2.52 in
64.01 mm
Ab - Cage-Cone Frontface Clearance 0.04 in
1.02 mm
Aa - Cage-Cone Backface Clearance 0.04 in
1.02 mm
a - Effective Center Location3 -0.13 in
-3.30 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 4360 lbf
19400 N
C1 - Dynamic Radial Rating (1 million revolutions)2 16800 lbf
74800 N
C0 - Static Radial Rating 16700 lbf
74200 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 2980 lbf
13300 N
K - Factor1 1.46
e - ISO Factor2 0.4
Y - ISO Factor3 1.5
G1 - Heat Generation Factor (Roller-Raceway) 23.3
G2 - Heat Generation Factor (Rib-Roller End) 13.3
Cg - Geometry Factor 0.0739


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken LM501349 - LM501311 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken LM501349 - LM501311 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



sale Tapered Roller LM501349 - LM501311 Bearings_TS Timken SPEC -Tancbearing

  • bearing LM501349 - LM501311 bearing
  • bearing LM501349 - LM501311 bearing
  • bearing LM501349 - LM501311 bearing
  • bearing LM501349 - LM501311 bearing
  • bearing LM501349 - LM501311 bearing
  • bearing LM501349 - LM501311 bearing
  • bearing LM501349 - LM501311 bearing
  • bearing LM501349 - LM501311 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 D:
73.431mm
m:
0.33kg
Brand:
TIMKENBearing
Model:
LM501349/LM501310
C0r:
74200N
Cr:
58400N
d:
41.275mm
Category:
TaperedRollerBearings
B:
19.812mm
C0r:
68000N
Cr:
55000N
NewModel:
KLM501349-LM501314
OilRPM:
94001/min
d:
41.275mm
D:
73.431mm
Model:
KLM501349-LM501314
GreaseRPM:
—1/min
Category:
TaperedRollerBearings
Brand:
FAGBearing
B:
19.812mm
m:
0.385kg
OldModel:
KLM501349-LM501314
Model:
LM501349/LM501311
Brand:
TIMKENBearing
C0r:
74200N
Cr:
58400N
d:
41.275mm
Category:
TaperedRollerBearings
m:
0.37kg
B:
19.812mm
D:
73.431mm
Model:
KLM501349.LM501310
D:
73.431mm
B:
19.812mm
OldModel:
KLM501349.LM501310
d:
41.275mm
Brand:
FAGBearing
OilRPM:
94001/min
m:
0.365kg
NewModel:
KLM501349-LM501310
C0r:
68000N
Category:
TaperedRollerBearings
Cr:
55000N
GreaseRPM:
—1/min
B:
19.812mm
Cr:
58400N
D:
73.431mm
Model:
LM501349/LM501314
m:
0.36kg
Brand:
TIMKENBearing
C0r:
74200N
d:
41.275mm
Category:
TaperedRollerBearings
Brand:
KOYOBearing
Model:
LM501349/LM501314
B:
19.812mm
d:
41.275mm
GreaseRPM:
52001/min
C0r:
73N
m:
0.353kg
D:
73.431mm
Cr:
57.8N
Category:
TaperedRollerBearings
OilRPM:
70001/min
