Timken LM501349 - LM501314 bearing

All our Timken LM501349 - LM501314 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken LM501349 - LM501314

Series LM501300
Cone Part Number LM501349
Cup Part Number LM501314
Design Units Imperial
Bearing Weight 0.8000 lb
0.4000 Kg
Cage Type Stamped Steel
D - Cup Outer Diameter 2.8910 in
73.431 mm
d - Cone Bore 1.6250 in
41.275 mm
B - Cone Width 0.7800 in
19.812 mm
C - Cup Width 0.6537 in
16.604 mm
T - Bearing Width 0.8437 in
21.430 mm
Z - Number of Rollers Per Row 19
R - Cone Backface "To Clear" Radius1 0.140 in
3.560 mm
r - Cup Backface "To Clear" Radius2 0.030 in
0.76 mm
da - Cone Frontface Backing Diameter 1.89 in
48.01 mm
db - Cone Backface Backing Diameter 2.13 in
54.10 mm
Da - Cup Frontface Backing Diameter 2.80 in
71.10 mm
Db - Cup Backface Backing Diameter 2.56 in
65.02 mm
Ab - Cage-Cone Frontface Clearance 0.04 in
1.02 mm
Aa - Cage-Cone Backface Clearance 0.04 in
1.02 mm
a - Effective Center Location3 -0.13 in
-3.30 mm
C90 - Dynamic Radial Rating (90 million revolutions)1 4360 lbf
19400 N
C1 - Dynamic Radial Rating (1 million revolutions)2 16800 lbf
74800 N
C0 - Static Radial Rating 16700 lbf
74200 N
Ca90 - Dynamic Thrust Rating (90 million revolutions)3 2980 lbf
13300 N
K - Factor1 1.46
e - ISO Factor2 0.4
Y - ISO Factor3 1.5
G1 - Heat Generation Factor (Roller-Raceway) 23.3
G2 - Heat Generation Factor (Rib-Roller End) 13.3
Cg - Geometry Factor 0.0739


             In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken LM501349 - LM501314 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken LM501349 - LM501314 Bearings, welcome to your calling.
bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF



please contact EMAIL :sales@tanchin.hk for any inquiry



Tapered Roller LM501349 - LM501314 Bearings_TS SPEC specifications Timken -Tancbearing

  • bearing LM501349 - LM501314 bearing
  • bearing LM501349 - LM501314 bearing
  • bearing LM501349 - LM501314 bearing
  • bearing LM501349 - LM501314 bearing
  • bearing LM501349 - LM501314 bearing
  • bearing LM501349 - LM501314 bearing
  • bearing LM501349 - LM501314 bearing
  • bearing LM501349 - LM501314 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

 D:
73.431mm
OilRPM:
70001/min
Brand:
KOYOBearing
Cr:
57.8N
Category:
TaperedRollerBearings
GreaseRPM:
52001/min
m:
0.334kg
Model:
LM501349/LM501310
B:
19.812mm
d:
41.275mm
C0r:
73N
Cr:
58400N
Category:
TaperedRollerBearings
B:
19.812mm
m:
0.37kg
D:
73.431mm
Model:
LM501349/LM501311
d:
41.275mm
C0r:
74200N
Brand:
TIMKENBearing
Cr:
57.8N
Brand:
KOYOBearing
B:
19.812mm
m:
0.353kg
C0r:
73N
GreaseRPM:
52001/min
Model:
LM501349/LM501314
D:
73.431mm
Category:
TaperedRollerBearings
d:
41.275mm
OilRPM:
70001/min
Category:
TaperedRollerBearings
B:
19.812mm
Model:
LM501349/LM501314
C0r:
74200N
d:
41.275mm
m:
0.36kg
Brand:
TIMKENBearing
Cr:
58400N
D:
73.431mm
m:
0.365kg
NewModel:
KLM501349-LM501310
Category:
TaperedRollerBearings
Model:
KLM501349.LM501310
C0r:
68000N
OldModel:
KLM501349.LM501310
Cr:
55000N
OilRPM:
94001/min
d:
41.275mm
GreaseRPM:
—1/min
D:
73.431mm
B:
19.812mm
Brand:
FAGBearing
B:
19.812mm
Model:
LM501349/LM501310
m:
0.33kg
d:
41.275mm
C0r:
74200N
D:
73.431mm
Category:
TaperedRollerBearings
Brand:
TIMKENBearing
Cr:
58400N
