Timken M802047 - M802011 bearing

All our Timken M802047 - M802011 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken M802047 - M802011

Series

M802000

Cone Part Number

M802047

Cup Part Number

M802011

Design Units

Imperial

Bearing Weight

1.4000 lb
0.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.2500 in
82.550 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.0100 in
25.654 mm

C - Cup Width

0.7950 in
20.193 mm

T - Bearing Width

1.0450 in
26.543 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.030 in
0.760 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

1.99 in
50.55 mm

db - Cone Backface Backing Diameter

2.05 in
52.07 mm

Da - Cup Frontface Backing Diameter

3.13 in
79.00 mm

Db - Cup Backface Backing Diameter

2.76 in
70.10 mm

Ab - Cage-Cone Frontface Clearance

0.07 in
1.78 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.12 in
-3.00 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5340 lbf
23800 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20600 lbf
91700 N

C0 - Static Radial Rating

25300 lbf
112000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

4990 lbf
22200 N

K - Factor¹

1.07

e - ISO Factor²

0.55

Y - ISO Factor³

1.1

G1 - Heat Generation Factor (Roller-Raceway)

30.9

G2 - Heat Generation Factor (Rib-Roller End)

11.9

Cg - Geometry Factor

0.0899

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken M802047 - M802011 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken M802047 - M802011 Bearings, welcome to your calling.
