Timken M802048 - M802011 bearing

All our Timken M802048 - M802011 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken M802048 - M802011

Series

M802000

Cone Part Number

M802048

Cup Part Number

M802011

Design Units

Imperial

Bearing Weight

1.4000 lb
0.6000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.2500 in
82.550 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

1.0100 in
25.654 mm

C - Cup Width

0.7950 in
20.193 mm

T - Bearing Width

1.0450 in
26.543 mm

Z - Number of Rollers Per Row

18

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.130 in
3.30 mm

da - Cone Frontface Backing Diameter

1.99 in
50.55 mm

db - Cone Backface Backing Diameter

2.24 in
56.90 mm

Da - Cup Frontface Backing Diameter

3.13 in
79.00 mm

Db - Cup Backface Backing Diameter

2.76 in
70.10 mm

Ab - Cage-Cone Frontface Clearance

0.07 in
1.78 mm

Aa - Cage-Cone Backface Clearance

0.09 in
2.29 mm

a - Effective Center Location³

-0.12 in
-3.00 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5340 lbf
23800 N

C1 - Dynamic Radial Rating (1 million revolutions)²

20600 lbf
91700 N

C0 - Static Radial Rating

25300 lbf
112000 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

4990 lbf
22200 N

K - Factor¹

1.07

e - ISO Factor²

0.55

Y - ISO Factor³

1.1

G1 - Heat Generation Factor (Roller-Raceway)

30.9

G2 - Heat Generation Factor (Rib-Roller End)

11.9

Cg - Geometry Factor

0.0899

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken M802048 - M802011 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken M802048 - M802011 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

price Timken specifications Tapered Roller M802048 - M802011 Bearings_TS -Tancbearing

M802048 - M802011 bearing
M802048 - M802011 bearing
M802048 - M802011 bearing
M802048 - M802011 bearing
M802048 - M802011 bearing
M802048 - M802011 bearing
M802048 - M802011 bearing
M802048 - M802011 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

Model:

M802048/M802011

d:

41.275mm

GreaseRPM:

49001/min

C0r:

105N

Category:

TaperedRollerBearings

Cr:

83.7N

B:

25.654mm

m:

0.63kg

Brand:

KOYOBearing

OilRPM:

65001/min

D:

82.55mm

d:

41.275mm

Model:

KM802048-M802011

D:

82.55mm

GreaseRPM:

—1/min

C0r:

111000N

m:

0.661kg

Brand:

FAGBearing

OldModel:

KM802048-M802011

NewModel:

KM802048-M802011

Category:

TaperedRollerBearings

Cr:

83000N

OilRPM:

78001/min

B:

25.654mm

B:

25.654mm

m:

0.62kg

Brand:

TIMKENBearing

d:

41.275mm

Model:

M802048/M802011

Cr:

84900N

C0r:

112000N

Category:

TaperedRollerBearings

D:

82.550mm

Model:

4T-M802048/M802011

Cr:

80.5N

d:

41.275mm

Category:

TaperedRollerBearings

C0r:

104N

GreaseRPM:

46001/min

B:

25.654mm

m:

0.642kg

OilRPM:

61001/min

Brand:

NTNBearing

NewModel:

4T-M802048/M802011

D:

82.55mm
