Timken M903345 - M903310 bearing

All our Timken M903345 - M903310 bearings ensure quality

Price :$1.08,please contact sales@tanchin.hk Timken M903345 - M903310

Series

M903300

Cone Part Number

M903345

Cup Part Number

M903310

Design Units

Imperial

Bearing Weight

1.7000 lb
0.8000 Kg

Cage Type

Stamped Steel

D - Cup Outer Diameter

3.6250 in
92.075 mm

d - Cone Bore

1.6250 in
41.275 mm

B - Cone Width

0.9375 in
23.813 mm

C - Cup Width

0.6563 in
16.670 mm

T - Bearing Width

1.0313 in
26.195 mm

Z - Number of Rollers Per Row

16

R - Cone Backface "To Clear" Radius¹

0.140 in
3.560 mm

r - Cup Backface "To Clear" Radius²

0.060 in
1.52 mm

da - Cone Frontface Backing Diameter

2.13 in
54.10 mm

db - Cone Backface Backing Diameter

2.56 in
65.02 mm

Da - Cup Frontface Backing Diameter

3.50 in
87.90 mm

Db - Cup Backface Backing Diameter

3.07 in
77.98 mm

Ab - Cage-Cone Frontface Clearance

0.13 in
3.30 mm

Aa - Cage-Cone Backface Clearance

0.19 in
4.83 mm

a - Effective Center Location³

0.14 in
3.60 mm

C90 - Dynamic Radial Rating (90 million revolutions)¹

5910 lbf
26300 N

C1 - Dynamic Radial Rating (1 million revolutions)²

22800 lbf
101000 N

C0 - Static Radial Rating

20800 lbf
92500 N

C_a90 - Dynamic Thrust Rating (90 million revolutions)³

8410 lbf
37400 N

K - Factor¹

0.7

e - ISO Factor²

0.83

Y - ISO Factor³

0.72

G1 - Heat Generation Factor (Roller-Raceway)

25.6

G2 - Heat Generation Factor (Rib-Roller End)

13.1

Cg - Geometry Factor

0.0948

In 1895, Henry. Timken, the founder of the Timken Company, invented a conical roller TIMKEN bearing in use of axle, it is Tapered Roller Bearings. Timken Bearings becomes the largest Tapered Roller Bearings Manufacture, it also enjoys high reputation in bearings field. it provides the professional Timken M903345 - M903310 Bearings, there are abundant Timken bearings stock in warehouse, if you need Timken M903345 - M903310 Bearings, welcome to your calling.

bearings brand

FAG － NSK － NTN － INA － NACHI － IKO － KOYO － FYH － ASAHI － RHP － STEYR － FAFNIR － SBC － TSUBAKI － KINGON － BARDEN － AET － GMN － MAC－ RIV － THK － DKF － MRC － IJK － ZKL － SNR － ASK － NMB － SNFA － TORRINGTON － SNF

please contact EMAIL :sales@tanchin.hk for any inquiry

Timken Tapered Roller M903345 - M903310 Bearings_TS dimensions specifications -Tancbearing

M903345 - M903310 bearing
M903345 - M903310 bearing
M903345 - M903310 bearing
M903345 - M903310 bearing
M903345 - M903310 bearing
M903345 - M903310 bearing
M903345 - M903310 bearing
M903345 - M903310 bearing

please contact EMAIL :sales@tanchin.hk for any inquiry

OilRPM:

50001/min

m:

0.758kg

D:

92.075mm

Model:

4T-M903345/M903310

B:

23.812mm

Cr:

72.5N

Category:

TaperedRollerBearings

d:

41.275mm

C0r:

81.5N

GreaseRPM:

38001/min

Brand:

NTNBearing

NewModel:

4T-M903345/M903310

B:

23.812mm

Cr:

79200N

m:

0.77kg

Brand:

TIMKENBearing

d:

41.275mm

Model:

M903345/M903310

C0r:

92500N

Category:

TaperedRollerBearings

D:

92.075mm
